W240

Position lamps / clearance lights

catalogue number click and see the details	cable / wires	light source	mounting side	operating voltage	position / front clearance	position / side clearance	position / rear clearance	reflective device	side indicator	pieces in the box
1597	22cm 3x0,5mm²	LED	Universal	12V-24V						80
1597 ADR	22cm FLRYY	LED	Universal	12V-24V						80
1598	24cm LGY-S 2x0,75mm²	LED	Universal	12V-24V						80
1598 ADR	24cm FLRYY 2x0,75mm²	LED	Universal	12V-24V						80
1599	24cm LGY-S 2x0,75mm²	LED	Universal	12V-24V						80
1599 ADR	24cm FLRYY 2x0,75mm²	LED	Universal	12V-24V						80
1600	24cm LGY-S 2x0,75mm²	LED	Universal	12V-24V						80
1600 ADR	24cm FLRYY 2x0,75mm²	LED	Universal	12V-24V						80
1597 NN	22cm 3x0,5mm²	LED	Universal	12V-24V						80
1597 NN ADR	22cm FLRYY	LED	Universal	12V-24V						80
1598 NN	24cm LGY-S 2x0,75mm²	LED	Universal	12V-24V						80
1598 NN ADR	24cm FLRYY 2x0,75mm²	LED	Universal	12V-24V						80
1599 NN	24cm LGY-S 2x0,75mm²	LED	Universal	12V-24V						80
1599 NN ADR	24cm FLRYY 2x0,75mm²	LED	Universal	12V-24V						80
1600 NN	24cm LGY-S 2x0,75mm²	LED	Universal	12V-24V						80
1600 NN ADR	24cm FLRYY 2x0,75mm²	LED	Universal	12V-24V						80

The new W240 series are innovative front, rear and side marker/position lamps that emit light on the ground, drawing lines around the vehicle, showing its outline on the road.

The marker lamps produced with LED technology, together with the modern lens with neon elements, create a light pleasant to the eye and also create a distinctive line on the ground. The remarkable design of the lamps combines side position light, front or rear position/marker light along with retroreflector, which is another advantage as it increases the safety of parked vehicles.

Our W240 series lamps meet all homologation requirements and have been tested for environmental protection, receiving IP6K9K. WAŚ marker lamps are electromagnetically compatible. They are also characterized by a lack of polarization, which means that the lamps work properly regardless of how the + and - cables are connected. Moreover, the lamps are universal in voltage, operating within the range of 12V - 24V.

For the production of the latest family of lamps, we used the highest quality materials, with increased resistance to mechanical damage and perfectly suited for changing weather conditions. The new W240 lamp series, like all WAŚ lamps, was developed and manufactured in Poland.

Power consumption 12V 24V

position light 2,2W 4,4W

Method of mounting the lamps on a vehicle:
For the modern W240 series lamps we have developed a new method of mounting on a vehicle. First, you need to mount the mounting base to the vehicle using screws, and then you place the lamp in the base by pressing it. The special clip design holds the lamp firmly in the base. Traditionally, it is also possible to mount the lamps using a bracket. In this case, the mounting base with the lamp is connected with the bracket.
